Laser melting (metal 3D printing) systems

CAD driven direct manufacturing in a wide range of metals. Renishaw's laser melting is a pioneering, additive manufacturing process capable of producing fully dense metal parts direct from 3D CAD.

Page contentDownloadsCall your local office Contact us online

Renishaw's laser melting (metal 3D printing)

Renishaw's laser melting is an additive manufacturing technology that uses a high powered ytterbium fibre laser to fuse fine metallic powders together to form functional 3-dimensional parts.

The process is digitally driven, direct from sliced 3D CAD data, in layer thicknesses ranging from 20 µm to 100 µm that form a 2D cross section. The process then builds the part by distributing an even layer of metallic powder using a recoater, then fusing each layer in turn under a tightly controlled inert atmosphere. Once complete, the part is removed from the powder bed and undergoes heat treatment and finishing depending on the application.



















Typical applications for laser melting technology:

  • functional testing of production quality prototypes
  • manufacturing of organic or highly complex geometries
  • low volume manufacturing of complex metal parts in specialist materials

Browse

 AM250



  Software

 Additive applications
  AM250 laser melting machine    AM software   AM パーツ

Medical applications

Early adopters of laser melting in the medical orthopaedics sector saw benefits from the technology's ability to manufacture complex geometries and structures in high grade materials such as titanium. From patient specific hip implants to series volume production of orthopaedic implants featuring hybrid structures, laser melting has an established following in these sectors.

Industrial applications

From tooling inserts featuring conformal cooling channels through to lightweight structures for aerospace and high technology applications, laser melting significantly reduces the constraints on designers. This design freedom results in optimised structures and shapes that would otherwise be constrained by conventional processes or the tooling requirements of large volume production. Laser melting helps to reduce lead times, reduce tooling costs and permits the creation of designs not previously possible.

AM125

The AM125 has been discontinued. However, we will continue to provide support and full spares capability for the foreseeable future.

Please contact am.support@renishaw.com for assistance.

Downloads

Next steps

Contact us online if you require more information or you have a pricing query, or alternatively you may like to speak directly to your local Renishaw office.
