REVO system

5-axis motion and infinite positioning multi-sensor system providing touch-trigger, scanning, surface finish and non-contact measurement

REVO-2 probe comparison chart


RSP2RSP3-1 to -4RSP3-6SFP2RVPRFP1

Tip sensing

YesNoNoYesn/an/a
Non-contact NoNoNoNoYesYes
Head scanning YesNoNoNoNoNo
Cranked styli NoYesMax. 50 mmYesn/an/a
Sensing axes

XY scan

XYZ touch

XYZ scan

XYZ touch

XY scan

XYZ touch

Scale and readhead2D sensor array2D sensor array
Automatic probe changingYesYesYesYesYesYes
Automatic stylus / module changingYesYesYesYesYesYes

NOTE: RSP3-6 is XYZ touch and XY scan only.


Part number

REVO-2 5-axis scanning system kits

REVO-2 entry kit (includes 1 × REVO-2 head kit, 1 × RSP2 V2 probe, 1 × RSH250 kit, 1 × datum ball kit)

A-5518-1095

REVO-2 S5 controller kit (including 1 UCC S5, 1 SPA3 amp, 1 REVO air filer assembly, 1 REVO 6 mm air pipe, 1 UCC T3 connector kit, 1 MCU5-2 joystick, 1 PSU)

A-5518-0096

REVO-2 S5 controller kit (including 1 UCC S5, 1 SPA3 amp, 1 REVO air filer assembly, 1 REVO 6 mm air pipe, 1 UCC T3 connector kit, 1 MCU W-2 joystick, MCU W battery pack (2 batteries), 1 PSU)

A-5518-0098

REVO RSP2 probe

RSP2 V2 probe (probe only)

A-3060-0028

RSP2 stylus holder kits

RSH175 stylus holder kit (including 1 × RSH175, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-3060-0024

RSH250 stylus holder kit (including 1 RSH250, 2 6 by 10 M2 styli, 1 stylus tools)

A-3060-0021

RSH350 stylus holder kit (including 1 RSH350, 2 6 by 10 M2 styli, 1 stylus tools)

A-3060-0022

RSH450 stylus holder kit (including 1 RSH450, 2 6 by 10 M2 styli, 1 stylus tools)

A-3060-0026

RSH500 stylus holder kit (including 1 RSH500, 2 6 by 10 M2 styli, 1 stylus tools)

A-3060-0023

REVO RSP3 probe kits

REVO RSP3-1 probe kit (including 1 RSP3-1 probe, 1 RSH3-1 stylus holder, 1 20 mm extension and styli)

A-3060-0331

REVO RSP3-2 probe kit (including 1 RSP3-2 probe, 1 RSH3-2 stylus holder, 1 20 mm extension and styli)

A-3060-0332

REVO RSP3-3 probe kit (including 1 RSP3-3 probe, 1 RSH3-3 stylus holder, 1 20 mm extension and styli)

A-3060-0333

REVO RSP3-4 probe kit (including 1 RSP3-4 probe, 1 RSH3-4 stylus holder, 1 20 mm extension and styli)

A-3060-0334

RSP3 stylus holder kits

RSH3-1 stylus holder kit (includes 1 stylus holder, 1 PA25-RSH3 port adapter, 1 stylus tools)

A-3061-2521

RSH3-2 stylus holder kit (includes 1 stylus holder, 1 PA25-RSH3 port adapter, 1 stylus tools)

A-3061-2522

RSH3-3 stylus holder kit (includes 1 stylus holder, 1 PA25-RSH3 port adapter, 1 stylus tools)

A-3061-2523

RSH3-4 stylus holder kit (includes 1 stylus holder, 1 PA25-RSH3 port adapter, 1 stylus tools)

A-3061-2524

RSP3-6 probe

RSP3-6 probe (probe only)

A-6084-0001

RSP3-6 stylus holder kits

RSH3-6c-500 kit for cranked styli (includes 1 stylus holder, 2 6 by 10 M2 styli, 1 stylus tools)

A-6084-0015

RSH3-6c-600 kit for cranked styli (includes 1 stylus holder, 2 6 by 10 M2 styli, 1 stylus tools)

A-6084-0016

RSH3-6-600 kit (includes 1 stylus holder, 2 6 by 10 M2 styli, 1 stylus tools)

A-6084-0006

RSH3-6-700 kit (includes 1 stylus holder, 2 6 by 10 M2 styli, 1 stylus tools)

A-6084-0007

RSH3-6-800 kit (includes 1 stylus holder, 2 6 by 10 M2 styli, 1 stylus tools)

A-6084-0008

REVO SFP2 kits

SFP2 combi kit #1 (A1 and A2 modules, single artefact)

A-5764-0001

SFP2 combi kit #2 (single artefact, no modules)

A-5764-0002

SFP2 combi kit #3 (A1 and A2 modules, triple artefact)

A-5764-0003

SFP2 combi kit #4 (triple artefact, no modules)

A-5764-0004

Single artefact kit (SFA1 and single artefact holding kit)

A-5764-0072

Triple artefact kit (SFA1, 2, 3 and triple artefact holding kit)

A-5764-0073

SFP2 probe and modules

SFM-A1 2 µm general purpose straight module (type A skid)

A1-D-02C90D

SFM-A1 5 µm general purpose straight module (type A skid)

A1-D-05C90D

SFM-A2 2 µm general purpose cranked module (type A skid)

A2-D-02C90D

SFM-A2 5 µm general purpose cranked module (type A skid)

A2-D-05C90D

SFM-B1 2 µm straight module with smaller skid for short lands (type B skid)

B1-D-02C90D

SFM-B1 5 µm straight module with smaller skid for short lands (type B skid)

B1-D-05C90D

SFM-B2 2 µm cranked module with smaller skid for short lands (type B skid)

B2-D-02C90D

SFM-B2 5 µm cranked module with smaller skid for short lands (type B skid)

B2-D-05C90D

SFM-B3 5 µm 90° module with smaller skid for pockets and grooves (type B skid)

B3-D-05C90D

SFM-B4 5 µm cranked module with smaller skid for reach into confined areas (type B skid)

B4-D-05C90D

SFM-B5 5 µm cranked module with smaller skid for reach into undercuts and grooves (type B skid)

B5-D-05C90D

SFM-C3 2 m straight module for small bores (type C skid)

C3-D-02C90D

SFM-C3 5 m straight module for small bores (type C skid)

C3-D-05C90D

SFM-D1 2 µm 90° module for extra reach (type D skid)

D1-D-02C90D

SFM-D1 5 µm 90° module for extra reach (type D skid)

D1-D-05C90D

SFM-E1 2 µm long straight module with 2-part skid (type E skid)

E1-D-02C90D

SFM-E1 5 µm long straight module with 2-part skid (type E skid)

E1-D-05C90D

SFM-E2 5 µm long straight module with 2-part skid (type E skid)

E2-D-05C90D

SFM-G1 Grooved engine bores prepared for PTWA coating (type G skid)

G1-D-10C30C

SFM-H1 automatic transmission valve bodies, minimum feature access (mm): 9 122 (max. depth) (type H skid)

H1-D-02C90D

SFM-H1 5 m automatic transmission valve bodies, minimum feature access (mm): 9 122 (max. depth) (type H skid)

H1-D-05C90D

Accessories

SFH-1 surface finish module holder

A-5764-0080

SFH-2 surface finish module holder

A-5764-0081

SFA1 3.0 SIN artefact (SFA1 plate with UKAS certificate)

A-5764-0060

SFA2 0.5 SIN artefact (SFA2 plate with UKAS certificate)

A-5764-0061

SFA3 0.4 ST artefact (SFA3 plate with UKAS certificate)

A-5764-0062

OFA optical flat artefact (* Special product)

A-5764-3142

Single artefact holder mounting kit. Contains: SFAH-1 single plate holder, rack adaptor, leg adaptor, fixings for all options, tools

A-5764-0070

Triple artefact holder mounting kit. Contains: SFAH-2 triple plate holder, rack adaptor, leg adaptor, fixings for all options, tools

A-5764-0071

TFP tip find probe kit (incl TP20 LF mod, stylus, PL24 cable)

A-5764-0063

MST module setting tool

A-5764-0091

System storage box

A-5764-0090

Software

MODUS surface texture - standard

M-5639-0228

MODUS surface texture - advanced

M-5639-0227

REVO-2 RVP kits

RVP REVO-2 vision probe kit

A-5378-0080

VM10 vision module kit

A-5378-0082

VM11-2 vision module kit

A-5378-0093

VM12 vision module

A-5378-0088

VPCP vision probe change port kit

A-5378-0081

VMCP vision module change port kit

A-5378-0083

VA11 vision artefact kit

A-5378-0089

RFP system kit

RFP full kit (includes 1 × RFP1 probe, 1 × FA10 calibration artefact, 1 × VPCP change port kit)

A-5417-0011

RFP system hardware

RFP1 probe (probe only)

A-5417-0010

FA10 calibration artefact

A-5417-0021

RFP system software

RFP inspection planner (supplied by Flexera)
CS-SOF-SW-01-0270
RFP digitiser (supplied by Flexera)
CS-SOF-SW-01-0271

RFP inspection planner (supplied on a dongle)

A-5871-5000

RFP digitiser (supplied on a dongle)

A-5871-5010

REVO rack kits

REVO MRS2 rack kit #1 (includes 1 × MRS2 400 mm leg kit, 1 × MRS2 400 mm rail kit, 2 × RCP2, 1 × TDA) - 400 mm of rail space

A-3060-2631

REVO MRS2 rack kit #2 (includes 1 × MRS2 400 mm leg kit, 1 × MRS2 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 600 mm of rail space

A-3060-2632

REVO MRS2 rack kit #3 (includes 1 × MRS2 600 mm leg kit, 1 × MRS2 600 mm rail kit, 1 × MRS2 front spaced 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 1200 mm of rail space

A-3060-2633

REVO MRS2 rack kit #4 (includes 1 × MRS2 800 mm leg kit, 1 × MRS2 600 mm rail kit, 1 × MRS2 front spaced 600 mm rail kit, 1 × MRS2 back spaced 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 1800 mm of rail space

A-3060-2634

REVO MRS2 rack kit #5 (includes 1 × MRS2 600 mm leg kit, 1 × MRS2 1000 mm rail kit, 1 × MRS2 front spaced 1000 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 2000 mm of rail space

A-3060-2635

REVO MRS2 rack kit #6 (includes 1 × MRS2 800 mm leg kit, 1 × MRS2 1000 mm rail kit, 1 × MRS2 front spaced 1000 mm rail kit, 1 × MRS2 back spaced 1000 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 3000 mm of rail space

A-3060-2636

REVO rack ports and rack accessories

REVO RCP2 change port for RSP2, SFP1 and RSP3-6 stylus holders

A-3060-0090

REVO RCP TC-2 thermally controlled change port for REVO probes

A-3061-0310

REVO RCP TC PSU unit

A-3061-0302

RCP TC-3 high force storage port

A-3061-0320

REVO FCR25 flexible change rack kit for changing RSH3 stylus holders: three port unit for MRS system (includes 1 FCR25, 3 PA25-RSH3, 1 REVO FCR25 adaptor kit)

A-3061-0105

TDA (tip datum artefact)

A-3060-0085

DC link cable

A-3060-0015

1.5 m dc extension cable

A-3060-0016

5 m dc extension cable

A-3060-0017

10 m dc extension cable

A-3060-0018

REVO FCR25 adaptor

A-3061-0101

REVO accessories

REVO datum ball kit (including 45 mm datum ball in wooden box with M6, M8, M10, 5/16, 3/8 mounting studs and spanner set)

A-3060-0310

REVO mechanical fuse mount (crash protection)

A-3060-0300

REVO RCP door replacement kit

A-3061-1962

PA25-RSH3 kit (includes 3 × PA25-RSH3 port inserts)

A-3061-2530

REVO air pipe 6 mm O/D × 20 m

A-3060-0082

REVO air filter set

A-3060-0070

15 m cable for use with PH20 and REVO

A-5669-0015

25 m cable for use with PH20 and REVO

A-5759-0025

30 m cable for use with REVO

A-5669-0030

REVO Y cable adaptor kit

A-3060-0045
