SFM-C2

Technical drawing:  Technical drawing:  SFM-C2

Enhanced access and inspection capability for integrated surface finish measurement

Features

The C-series of modules have the ability to locate the stylus in small diameter bores without significant degradation in performance. The skid and stylus are inline so that both travel along the axis of the bore.

NOTE: Not compatible with SFH-2.

Typical applications

Automotive engine valve guide ways.


Diamond tip radius (μm)

2 or 5

Surface finish measurement range (μm)

2 μm modules

5 μm modules


6.3 to 0.05 Ra

6.3 to 0.10 Ra

Typical surface finish accuracy (of nominal Ra) *

±(10% + 35 nm)

Skid / stylus arrangement

In-line (stylus lagging skid)

Skid material

Tungsten carbide

Nominal stylus tip protrusion beyond skid (mm)

0.37

Minimum feature access (mm)

Ø5 × 50

Skid length / radius (mm)

4.6 / 40

Skid width / radius (mm)

2.5 / 1.25

Skid contact force (N)

0.15

Stylus contact force (N)

0.003

SFM / SFH knuckle adjustment range

±90°

Weight (g)

12

Resolution (nm)

1

Measurement speed (mm/s)

Up to 1

Stylus holder compatibility

SFH-1 only

Lateral scanning capability

No

SFM-C2 dimension image

Data sheets

  • Data sheet:  SFM-C2
    Data sheet: SFM-C2

    Enhanced access and inspection capability for integrated surface finish measurement


Part number

REVO SFP2 kits

SFP2 combi kit #1 (A1 and A2 modules, single artefact)

A-5764-0001

SFP2 combi kit #2 (single artefact, no modules)

A-5764-0002

SFP2 combi kit #3 (A1 and A2 modules, triple artefact)

A-5764-0003

SFP2 combi kit #4 (triple artefact, no modules)

A-5764-0004

Single artefact kit (SFA1 and single artefact holding kit)

A-5764-0072

Triple artefact kit (SFA1, 2, 3 and triple artefact holding kit)

A-5764-0073

SFP2 probe and modules

SFM-A1 2 µm general purpose straight module (type A skid)

A1-D-02C90D

SFM-A1 5 µm general purpose straight module (type A skid)

A1-D-05C90D

SFM-A2 2 µm general purpose cranked module (type A skid)

A2-D-02C90D

SFM-A2 5 µm general purpose cranked module (type A skid)

A2-D-05C90D

SFM-B1 2 µm straight module with smaller skid for short lands (type B skid)

B1-D-02C90D

SFM-B1 5 µm straight module with smaller skid for short lands (type B skid)

B1-D-05C90D

SFM-B2 2 µm cranked module with smaller skid for short lands (type B skid)

B2-D-02C90D

SFM-B2 5 µm cranked module with smaller skid for short lands (type B skid)

B2-D-05C90D

SFM-B3 5 µm 90° module with smaller skid for pockets and grooves (type B skid)

B3-D-05C90D

SFM-B4 5 µm cranked module with smaller skid for reach into confined areas (type B skid)

B4-D-05C90D

SFM-B5 5 µm cranked module with smaller skid for reach into undercuts and grooves (type B skid)

B5-D-05C90D

SFM-C3 2 µm straight module for small bores (type C skid)

C3-D-02C90D

SFM-C3 2 µm straight module for small bores (type C skid)

C3-D-05C90D

SFM-D1 2 µm 90° module for extra reach (type D skid)

D1-D-02C90D

SFM-D1 5 µm 90° module for extra reach (type D skid)

D1-D-05C90D

SFM-E1 2 µm long straight module with 2-part skid (type E skid)

E1-D-02C90D

SFM-E1 5 µm long straight module with 2-part skid (type E skid)

E1-D-05C90D

SFM-E2 5 µm long straight module with 2-part skid (type E skid)

E2-D-05C90D

SFM-G1 Grooved engine bores prepared for PTWA coating (type G skid)

G1-D-10C30C

SFM-H1 automatic transmission valve bodies, minimum feature access (mm): Ø9 × 122 (max. depth) (type H skid)

H1-D-02C90D

SFM-H1 5 µm automatic transmission valve bodies, minimum feature access (mm): 9 122 (max. depth) (type H skid)

H1-D-05C90D

Accessories

SFH-1 surface finish module holder

A-5764-0080

SFH-2 surface finish module holder

A-5764-0081

SFA1 3.0 SIN artefact (SFA1 plate with UKAS certificate)

A-5764-0060

SFA2 0.5 SIN artefact (SFA2 plate with UKAS certificate)

A-5764-0061

SFA3 0.4 ST artefact (SFA3 plate with UKAS certificate)

A-5764-0062

OFA optical flat artefact (* special product)

A-5764-3142

Single artefact holder mounting kit. Contains: SFAH-1 single plate holder, rack adaptor, leg adaptor, fixings for all options, tools

A-5764-0070

Triple artefact holder mounting kit. Contains: SFAH-2 triple plate holder, rack adaptor, leg adaptor, fixings for all options, tools

A-5764-0071

TFP tip find probe kit (including TP20 LF mod, stylus, PL24 cable)

A-5764-0063

MST module setting tool

A-5764-0091

System storage box

A-5764-0090
