REVO legacy head

REVO beim Scannen eines Zylinderkopfs

A highly accurate dynamic measuring head and probe system which maximises measurement throughput.

Product tree

Increased measuring speed

  • Up to 500 mm/sec resulting in increased part throughput
  • Data collection rates up to 4,000 points per second
  • Infinite positioning and five-axis motion reduces non productive transitions between features
  • Rapid calibration with all positions inferred means more time measuring

WITH high system accuracy

  • 5-axis scanning minimises CMM motion and the associated dynamic errors
  • Stylus wear minimised by extremely low scanning forces
  • Infinite positioning and five-axis motion aid access to difficult features
  • Flexible tip sensing further adds to the systems' accuracy and flexibility

AND great flexibility

  • Maximum reach up to 800 mm* with maintained effective working length
  • Probe and stylus changing capability allowing flexibility and future probing technology compatibility
  • Renishaw UCCserver software application (based on I++ DME command protocol) provides the interface for REVO control
  • The removable probe system, used in conjunction with a low cost changer, provides added system flexibility

*  From centre of head rotation

Video: REVO show reel



REVO probe comparison chart



 RSP2

 RSP3

SFP1
 Tip sensing Yes No Yes
 Cranked styli No 50 mm  Yes
 Sensing axes

 XY scan
 XYZ touch

 XYZ scan
 XYZ touch

 N/A

 Probe changing

 Yes

 Yes

 Yes

 Stylus changing

 Yes

 Yes

 Yes

Dimensions

Dimensions in mm

Dimensions of the REVO head

Specification

 Operating temperature

 14 °C to 30 °C (57 °F to 86 °F)

 Storage temperature

 -10 °C to +70 °C (14 °F to 158 °F)

 Weight (excluding probe and cables)

 1.75 kg

 Height (overall)

 239 mm (9.41 in)

 B-axis

 92 mm (3.62 in ) square

 A-axis swept diameter

 118 mm (4.65 in)

 Movement speed

 3 revs/sec

 A-axis rotation angle

 -5° to +120°

 B-axis rotation angle

 Continuous

 Angular resolution

 0.08 arc sec (0.4 µm/100 mm)

 Bearings

 Air (refer to user guide for detail)

 Change rack system

 RCP TC for probe changing / RCP for stylus changing

 Mounting

 Quill mounting in the vertical orientation only (adaptor may be required)

Brochures and flyers

  • Brochure: REVO
    [222kB]
  • Flyer: SFP1 surface finish probe for REVO-2

    REVO-2 is the only scanning system for CMMs that simultaneously controls the motion of three machine and two head axes whilst collecting work piece data using its range of 2D and 3D tactile probes, surface roughness measurement probe and now non-contact vision probe too.

    [900kB]
  • Brochure: Renishaw retrofit

    Transform your old CMM with a new lease of life, speed and capability

    [1015kB]

Installation and user's guides

Case studies

Other

Declarations

 Part number
REVO 5-axis scanning system kits
REVO entry kit (includes 1 × REVO head kit, 1 × RSP2 V2 probe, 1 × RSH250 kit, 1 × datum ball kit)A-3060-0005
REVO head kit
REVO head kit (including 1 × REVO head, 1 × crash protection mounting kit, 1 × REVO tools, 1 × cleaning kit, 1 × CD ROM)A-3060-0040
REVO RSP2 probe
RSP2 V2 probe (probe only)A-3060-0028
RSP2 stylus holder kits
RSH175 stylus holder kit (including 1 × RSH175, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-3060-0024
RSH250 stylus holder kit (including 1 × RSH250, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-3060-0021
RSH350 stylus holder kit (including 1 × RSH350, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-3060-0022
RSH450 stylus holder kit (including 1 × RSH450, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-3060-0026
RSH500 stylus holder kit (including 1 × RSH500, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-3060-0023
REVO RSP3 probe kits
REVO RSP3-1 probe kit (including 1 × RSP3-1 probe, 1 × RSH3-1 stylus holder, 1 × 20 mm extension and styli)A-3060-0331
REVO RSP3-2 probe kit (including 1 × RSP3-1 probe, 1 × RSH3-2 stylus holder, 1 × 20 mm extension and styli)A-3060-0332
REVO RSP3-3 probe kit (including 1 × RSP3-3 probe, 1 × RSH3-3 stylus holder, 1 × 20 mm extension and styli)A-3060-0333
REVO RSP3-4 probe kit (including 1 × RSP3-4 probe, 1 × RSH3-4 stylus holder, 1 × 20 mm extension and styli)A-3060-0334
RSP3 stylus holder kits
RSH3-1 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)A-3061-2521
RSH3-2 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)A-3061-2522
RSH3-3 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)A-3061-2523
RSH3-4 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)A-3061-2524
RSP3-6 probe
RSP3-6 probe (probe only)A-6084-0001
RSP3-6 stylus holder kits
RSH3-6c-500 kit for cranked styli (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-6084-0015
RSH3-6c-600 kit for cranked styli (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-6084-0016
RSH3-6-600 kit (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-6084-0006
RSH3-6-700 kit (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-6084-0007
RSH3-6-800 kit (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)A-6084-0008
REVO SFP1 kits
SFP1 combi kit (includes 1 × SFP1, 1 × SFS-1, 1 × SFS-2, 1 × SFCP, 1 × SFA)A-5453-3000
SFP1 entry kit 1 (includes 1 × SFP1, 1 × SFS-1, 1 × SFCP, 1 × SFA)A-5453-3001
SFP1 entry kit 2 (includes 1 × SFP1, 1 × SFS-2, 1 × SFCP, 1 × SFA)A-5453-3002
SFP1A-5453-0025
SFS-1A-5453-0035
SFS-2A-5453-0045
SFCP (SFP1 C-axis port)A-5453-0065
SFA (surface finish probe calibration artefact)A-5453-0055
REVO rack kits
REVO MRS2 rack kit #1 (includes 1 × MRS2 400 mm leg kit, 1 × MRS2 400 mm rail kit, 2 × RCP2, 1 × TDA) - 400 mm of rail spaceA-3060-2631
REVO MRS2 rack kit #2 (includes 1 × MRS2 400 mm leg kit, 1 × MRS2 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 600 mm of rail spaceA-3060-2632
REVO MRS2 rack kit #3 (includes 1 × MRS2 600 mm leg kit, 1 × MRS2 600 mm rail kit, 1 × MRS2 front spaced 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 1200 mm of rail spaceA-3060-2633
REVO MRS2 rack kit #4 (includes 1 × MRS2 800 mm leg kit, 1 × MRS2 600 mm rail kit, 1 × MRS2 front spaced 600 mm rail kit, 1 × MRS2 back spaced 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 1800 mm of rail spaceA-3060-2634
REVO MRS2 rack kit #5 (includes 1 × MRS2 600 mm leg kit, 1 × MRS2 1000 mm rail kit, 1 × MRS2 front spaced 1000 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 2000 mm of rail spaceA-3060-2635
REVO MRS2 rack kit #6 (includes 1 × MRS2 800 mm leg kit, 1 × MRS2 1000 mm rail kit, 1 × MRS2 front spaced 1000 mm rail kit, 1 × MRS2 back spaced 1000 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 3000 mm of rail spaceA-3060-2636
REVO rack ports and rack accessories
REVO RCP2 change port for RSP2, SFP1 and RSP3-6 stylus holdersA-3060-0090
 REVO RCP TC-2 thermally controlled change port for REVO probesA-3061-0310
 REVO RCP TC PSU unitA-3061-0302
REVO FCR25 flexible change rack kit for changing RSH3 stylus holders: three port unit for MRS system (includes 1 × FCR25, 3 × PA25-RSH3, 1 × REVO FCR25 adaptor kit)A-3061-0105
TDA (tip datum artifact)A-3060-0085
DC link cableA-3060-0015
1.5 m dc extension cableA-3060-0016
5 m dc extension cableA-3060-0017
10 m dc extension cableA-3060-0018
REVO FCR25 adaptorA-3061-0101
REVO accessories
REVO datum ball kit (including 45 mm datum ball in wooden box with M6, M8, M10, 5/16, 3/8 mounting studs and spanner set)A-3060-0310
REVO mechanical fuse mount (crash protection)A-3060-0300
REVO RCP door replacement kitA-3061-1962
PA25-RSH3 kit (includes 3 × PA25-RSH3 port inserts)A-3061-2530
REVO air pipe 6 mm O/D × 20 mA-3060-0082
REVO air filter setA-3060-0070
15 m cable for use with PH20 and REVOA-5669-0015
25 m cable for use with PH20 and REVOA-5759-0025
30 m cable for use with REVOA-5669-0030
REVO Y cable adaptor kitA-3060-0045
