RCP TC-2 and RCP2

  • RCP / RCP TCProvide flexible, automatic, high speed changing between the range of REVO probes and stylus holders
  • Mount directly to the Renishaw MRS2 rack system

RCP TC-2

RCP TC-2 is a powered rack for use with the REVO probe range (RSP2, RSP3-# and SFP1). This rack maintains the probes at operating temperature whilst stored in the rack port. This maintains metrology of the system after a probe change.

RCP2

RCP2 is a passive rack port for use with the RSH range of stylus holders as well as the SFS-# styli.

RCP TC, RSP2, RCP and RSH350 guide

Dimensions

RCP TC-2 and RCP2

 RCP TC-2 and RCP2 dimensions

Other



Part number

REVO-2 5-axis scanning system kits


REVO-2 entry kit (includes 1 × REVO-2 head kit, 1 × RSP2 V2 probe, 1 × RSH250 kit, 1 × datum ball kit)

A-5518-1095

REVO-2 S5 controller kit (including 1 × UCC S5, 1 × SPA3 amp, 1 × REVO air filer assembly, 1 × REVO 6 mm air pipe, 1 × UCC T3 connector kit, 1 × MCU5-2 joystick, 1 × PSU)

A-5518-0096

REVO-2 S5 controller kit (including 1 × UCC S5, 1 × SPA3 amp, 1 × REVO air filer assembly, 1 × REVO 6 mm air pipe, 1 × UCC T3 connector kit, 1 × MCU W-2 joystick, MCU W battery pack (2 batteries), 1 × PSU)

A-5518-0098

REVO RSP2 probe


RSP2 V2 probe (probe only)

A-3060-0028

RSP2 stylus holder kits


RSH175 stylus holder kit (including 1 × RSH175, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-3060-0024

RSH250 stylus holder kit (including 1 × RSH250, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-3060-0021

RSH350 stylus holder kit (including 1 × RSH350, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-3060-0022

RSH450 stylus holder kit (including 1 × RSH450, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-3060-0026

RSH500 stylus holder kit (including 1 × RSH500, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-3060-0023

REVO RSP3 probe kits


REVO RSP3-1 probe kit (including 1 × RSP3-1 probe, 1 × RSH3-1 stylus holder, 1 × 20 mm extension and styli)

A-3060-0331

REVO RSP3-2 probe kit (including 1 × RSP3-2 probe, 1 × RSH3-2 stylus holder, 1 × 20 mm extension and styli)

A-3060-0332

REVO RSP3-3 probe kit (including 1 × RSP3-3 probe, 1 × RSH3-3 stylus holder, 1 × 20 mm extension and styli)

A-3060-0333

REVO RSP3-4 probe kit (including 1 × RSP3-4 probe, 1 × RSH3-4 stylus holder, 1 × 20 mm extension and styli)

A-3060-0334

RSP3 stylus holder kits


RSH3-1 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)

A-3061-2521

RSH3-2 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)

A-3061-2522

RSH3-3 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)

A-3061-2523

RSH3-4 stylus holder kit (includes 1 × stylus holder, 1 × PA25-RSH3 port adapter, 1 × stylus tools)

A-3061-2524

RSP3-6 probe


RSP3-6 probe (probe only)

A-6084-0001

RSP3-6 stylus holder kits


RSH3-6c-500 kit for cranked styli (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-6084-0015

RSH3-6c-600 kit for cranked styli (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-6084-0016

RSH3-6-600 kit (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-6084-0006

RSH3-6-700 kit (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-6084-0007

RSH3-6-800 kit (includes 1 × stylus holder, 2 × Ø6 by 10 M2 styli, 1 × stylus tools)

A-6084-0008

REVO SFP2 kits



SFP2 combi kit #1 (A1 and A2 modules, single artefact)

A-5764-0001

SFP2 combi kit #2 (single artefact, no modules)

A-5764-0002

SFP2 combi kit #3 (A1 and A2 modules, triple artefact)

A-5764-0003

SFP2 combi kit #4 (triple artefact, no modules)

A-5764-0004

Single artefact kit (SFA1 and single artefact holding kit)

A-5764-0072

Triple artefact kit (SFA1, 2, 3 and triple artefact holding kit)

A-5764-0073

Probe and modules



SFP2 surface finish probe with integral rotary C-axis


 SFM-A1 2 µm general purpose straight module (type A skid)

A-5764-0020

SFM-A1 5 µm general purpose straight module (type A skid)

A-5764-0022

SFM-A2 2 µm general purpose cranked module (type A skid)

A-5764-0021

SFM-A2 5 µm general purpose cranked module (type A skid)

A-5764-0023

SFM-B1 2 µm straight module with smaller skid for short lands (type B skid)

A-5764-0025

SFM-B1 5 µm straight module with smaller skid for short lands (type B skid)

A-5764-0050

SFM-B2 2 µm cranked module with smaller skid for short lands (type B skid)

A-5764-0026

SFM-B2 5 µm cranked module with smaller skid for short lands (type B skid)

A-5764-0024

SFM-B3 5 µm 90° module with smaller skid for pockets and grooves (type B skid)

A-5764-0027

SFM-B4 5 µm cranked module with smaller skid for reach into confined areas (type B skid)

A-5764-0034

SFM-B5 5 µm cranked module with smaller skid for reach into undercuts and grooves (type B skid)

A-5764-0029

SFM-C2 2 µm straight module for small bores (type C skid)

A-5764-0031

SFM-C2 5 µm straight module for small bores (type C skid)

A-5764-0032

SFM-D1 2 µm 90° module for extra reach (type D skid)

A-5764-0035

SFM-D1 5 µm 90° module for extra reach (type D skid)

A-5764-0036

SFM-E1 2 µm long straight module with 2-part skid (type E skid)

A-5764-0040

SFM-E1 5 µm long straight module with 2-part skid (type E skid)

A-5764-0038

SFM-E2 5 µm long straight module with 2-part skid (type E skid)

A-5764-0041

Accessories



SFH-1 surface finish module holder

A-5764-0080

SFH-2 surface finish module holder

A-5764-0081

SFA1 3.0 SIN artefact (SFA1 plate with UKAS certificate)

A-5764-0060

SFA2 0.5 SIN artefact (SFA2 plate with UKAS certificate)

A-5764-0061

SFA3 0.4 ST artefact (SFA3 plate with UKAS certificate)

A-5764-0062

OFA optical flat artefact (* Special product)

A-5764-3142

Single artefact holder mounting kit. Contains: SFAH-1 single plate holder, rack adaptor, leg adaptor, fixings for all options, tools

A-5764-0070

Triple artefact holder mounting kit. Contains: SFAH-2 triple plate holder, rack adaptor, leg adaptor, fixings for all options, tools

A-5764-0071

TFP tip find probe kit (incl TP20 LF mod, stylus, PL24 cable)

A-5764-0063

MST module setting tool

A-5764-0091

System storage box

A-5764-0090

Software



MODUS surface texture - standard

M-5639-0228

MODUS surface texture - advanced

M-5639-0227

REVO-2 RVP kits



RVP REVO-2 vision probe kit

A-5378-0080

VM10 vision module kit

A-5378-0082

VM11 vision module kit

A-5378-0087

VPCP vision probe change port kit

A-5378-0081

VMCP vision module change port kit

A-5378-0083

VA10 vision artefact kit

A-5378-0085

REVO rack kits



REVO MRS2 rack kit #1 (includes 1 × MRS2 400 mm leg kit, 1 × MRS2 400 mm rail kit, 2 × RCP2, 1 × TDA) - 400 mm of rail space

A-3060-2631

REVO MRS2 rack kit #2 (includes 1 × MRS2 400 mm leg kit, 1 × MRS2 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 600 mm of rail space

A-3060-2632

REVO MRS2 rack kit #3 (includes 1 × MRS2 600 mm leg kit, 1 × MRS2 600 mm rail kit, 1 × MRS2 front spaced 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 1200 mm of rail space

A-3060-2633

REVO MRS2 rack kit #4 (includes 1 × MRS2 800 mm leg kit, 1 × MRS2 600 mm rail kit, 1 × MRS2 front spaced 600 mm rail kit, 1 × MRS2 back spaced 600 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 1800 mm of rail space

A-3060-2634

REVO MRS2 rack kit #5 (includes 1 × MRS2 600 mm leg kit, 1 × MRS2 1000 mm rail kit, 1 × MRS2 front spaced 1000 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 2000 mm of rail space

A-3060-2635

REVO MRS2 rack kit #6 (includes 1 × MRS2 800 mm leg kit, 1 × MRS2 1000 mm rail kit, 1 × MRS2 front spaced 1000 mm rail kit, 1 × MRS2 back spaced 1000 mm rail kit, 2 × RCP TC-2, 2 × RCP2, 1 × RCP TC PSU unit, 1 × TDA) - 3000 mm of rail space

A-3060-2636

REVO rack ports and rack accessories



REVO RCP2 change port for RSP2, SFP1 and RSP3-6 stylus holders

A-3060-0090

REVO RCP TC-2 thermally controlled change port for REVO probes

A-3061-0310

REVO RCP TC PSU unit

A-3061-0302

RCP TC-3 high force storage port

A-3061-0320

REVO FCR25 flexible change rack kit for changing RSH3 stylus holders: three port unit for MRS system (includes 1 × FCR25, 3 × PA25-RSH3, 1 × REVO FCR25 adaptor kit)

A-3061-0105

TDA (tip datum artefact)

A-3060-0085

DC link cable

A-3060-0015

1.5 m dc extension cable

A-3060-0016

5 m dc extension cable

A-3060-0017

10 m dc extension cable

A-3060-0018

REVO FCR25 adaptor

A-3061-0101

REVO accessories



REVO datum ball kit (including 45 mm datum ball in wooden box with M6, M8, M10, 5/16, 3/8 mounting studs and spanner set)

A-3060-0310

REVO mechanical fuse mount (crash protection)

A-3060-0300

REVO RCP door replacement kit

A-3061-1962

PA25-RSH3 kit (includes 3 × PA25-RSH3 port inserts)

A-3061-2530

REVO air pipe 6 mm O/D × 20 m

A-3060-0082

REVO air filter set

A-3060-0070

15 m cable for use with PH20 and REVO

A-5669-0015

25 m cable for use with PH20 and REVO

A-5759-0025

30 m cable for use with REVO

A-5669-0030

REVO Y cable adaptor kit

A-3060-0045
