PL156 interpolator cable for IU80
| Cable name | Part number | Length |
| PL156 | A-1016-7129 | 60 mm (23.62 in) |
This straight cable has a 26-pin high-density D-type socket at end 'A' and is unterminated at end 'B' (the connector is not supplied). It is used to link the IU80 interpolator unit of the SP80 scanning probe system to the CC6 or equivalent counter card.
End 'A' | Wire | Signal | End 'A' | Wire | Signal |
|---|---|---|---|---|---|
1 | Red | X axis log A | 15 | Pink | Y axis log A |
2 | Not connected | - | 16 | Turquoise | Y axis log B |
3 | White / blue | IU80 reset | 17 | Grey | Y axis log B |
4 | Blue | IU80 error | 18 | Not connected | - |
5 | Not connected | Not connected | 19 | Not connected | - |
6 | Green | Z axis log | 20 | Red / blue | Z axis log A |
7 | Not connected | - | 21 | Green / red | Z axis log A |
8 | Yellow / blue | Probe present | 22 | Yellow / red | Z axis log B |
9 | Yellow | Green LED off | 23 | White / red | + 9 V to + 18 V |
10 | White | Red LED on | 24 | Black / red | + 5 V |
11 | Black | X axis log A | 25 | Brown / red | 0 V |
12 | Brown | X axis log B | 26 | Not connected | - |
13 | Violet | X axis log B | Shell | Screen | Screen |
14 | Orange | Y axis log A |
