PL17 and PL18 manual probe head cables
| Cable name | Part number | Length |
| PL17 | A-1023-7024 | 160 mm to 260 mm (6.3 in to 10.24 in) |
| PL18 | A-1023-7025 | 560 mm to 1.06 m (22.05 in to 41.73 in) |
These coiled cables have a 90° moulded 5-pin DIN plug at end 'A' and an in-line LEMO plug at end 'B'. They electrically connect Renishaw manual probe heads to the CMM quill.
End 'A' | End 'B' | Wire | Signal |
|---|---|---|---|
1 | 7 | Red | Head LED cathode |
2 | 11 | Screen | Screen |
3 | 13 | Yellow | Head LED anode |
4 | 9 | Blue | Probe circuit |
5 | 10 | Green | Probe circuit |
NOTE: A PL31 cable is available with inverted probe circuit pins if required.
