REVO five-axis measurement system for CMMs (jpg)
File size: 336 kB
Language: Language Independent
Dimensions: 960 x 1275 px
Unique laser correction allows Renscan5 to measure parts at ultra-high-speeds and acc/dec. A laser mounted in the REVO head shots a beam down a low-mass hollow stylus which is allowed to bend. A reflector mounted in the stylus tip returns the beam to a position sensor. Deflection of the return beam is used to calculate true tip position.
