Installation video: How to install RKLC incremental linear encoder scale (mp4)

File size: 120.54 MB Language: English Dimensions: 1280 x 720 px

The Renishaw RKLC encoder scale is a narrow, low cross-sectional area stainless steel tape scale featuring 20 μm or 40 μm pitch incremental graduations. RKLC scale is installed onto the axis substrate by a self-adhesive backing tape and it is mastered to the machine substrate, giving improved metrology, when the scale ends are rigidly fixed to the substrate. The scale is compatible with Renishaw’s VIONiC™, TONiC™ and QUANTiC™ incremental encoder series.
