Product A-8003-2380, Reference mark switch assembly

Product code: A-8003-2380

Reference mark switch assy
An optical or mechanical reference mark switch is typically used to determine the home position of each machine axis. Renishaw offer a mechanical Reference mark switch that is compatible with RCU. The assembly consists of a switch, which is repeatable up to ±2 µm and a cable gland, which accepts cables with nominal outside diameter of 4 to 8 mm. The Reference mark switch assembly is an optional extra. One reference mark switch should be used per axis.
[0B]

Reference mark switch assy

An optical or mechanical reference mark switch is typically used to determine the home position of each machine axis. Renishaw offer a mechanical Reference mark switch that is compatible with RCU. The assembly consists of a switch, which is repeatable up to ±2 µm and a cable gland, which accepts cables with nominal outside diameter of 4 to 8 mm. The Reference mark switch assembly is an optional extra. One reference mark switch should be used per axis.
[0B]

Price on application

Limited Availability

Longer lead times may apply.
Contact us for more information.

An optical or mechanical reference mark switch is typically used to determine the home position of each machine axis. Renishaw offers a mechanical reference mark switch that is compatible with RCU10 compensator.

The assembly consists of a switch, which is repeatable up to ±2 µm and a cable gland, which accepts cables with nominal outside diameter of 4 to 8 mm. One reference mark switch should be used per axis.
